// piptest.ino
// This example demonstrates some of the different capabilities
// of the RA8876. Formost, the two available PIP windows. PIP
// window 1 will always be on top of PIP window 2. It uses the
// setTMargins() function to create a window with a border that
// has adjustable thickness and cycle the colors of that border.
// It will repeatedly print the internal character set scrolling
// the window up as it prints. The window is basically a terminal
// window processing most ASCII control codes.
// There is a built in status line at the bottom of the screen that
// is 16 pixels in height with functions to support it.
// guages.ino
#include "Arduino.h"
//#include "Ra8876_Lite.h"
#include "RA8876_t3.h"
//#include "vt100.h"
#include <math.h>
#define RA8876_CS 10
#define RA8876_RESET 8
#define BACKLITE 7 //External backlight control connected to this Arduino pin
RA8876_t3 tft = RA8876_t3(RA8876_CS, RA8876_RESET); //Using standard SPI pins
// Array of RA8876 Basic Colors
PROGMEM uint16_t myColors[] = {
0x0000,
0xffff,
0xf800,
0xfc10,
0x8000,
0x07e0,
0x87f0,
0x0400,
0x001f,
0x051f,
0x841f,
0x0010,
0xffe0,
0xfff0,
0x8400,
0x07ff,
0x87ff,
0x0410,
0xf81f,
0xfc1f,
0x8010,
0xA145
};
uint8_t onOff = 1; // Enable PIP
uint8_t pipNo = 1; // PIP number 1
uint16_t xp = 0; // x coord. (source), for PIP
uint16_t yp = 0; // y coord. (source), for PIP
uint16_t xd = 0; // x coord. of displayed PIP window
uint16_t yd = 40; // y coord. of displayed PIP window
uint16_t xw = 320; // x width of displayed window
uint16_t yh = 240; // y height of displayed window
const PROGMEM char *title ="PIP+ DEMO\n";
const PROGMEM char *pip1 ="PIP WINDOW #1";
const PROGMEM char *pip2 ="PIP WINDOW #2";
uint8_t len = 0;
uint8_t c = 32;
int pipDelay = 0; // delayMicroseconds(pipDelay) Set to 0 for as fast as it gets
// or tone it down?
uint16_t thickness = 10; // drawRect() line thickness (Brush Size)
uint16_t x = 0;
uint16_t y = 0;
uint16_t w = 0;
uint16_t h = 0;
uint8_t fw = 0;
uint8_t fh = 0;
// Draw a border for the text window
void drawBorder(void) {
uint64_t color = 0;
fw = tft.getFontWidth();
fh = tft.getFontHeight();
x = (10*fw)-thickness;
y = (2*fh)-thickness;
w = tft.width()-(20*fw) + 2*thickness;
h = tft.height()-(4*fh) + 2*thickness;
color = random(0,65535) | 0x5555;
for(int i = 1; i <= thickness; i++) {
tft.drawRect(x, y, w, h, color);
x+=1;
y+=1;
w-=2;
h-=2;
}
}
// Put it all together
void setup() {
//I'm guessing most copies of this display are using external PWM
//backlight control instead of the internal RA8876 PWM.
//Connect a Teensy pin to pin 14 on the display.
//Can use analogWrite() but I suggest you increase the PWM frequency first so it doesn't sing.
pinMode(BACKLITE, OUTPUT);
digitalWrite(BACKLITE, HIGH);
tft.begin();
//initVT100();
tft.setFontSize(2,false);
tft.setCursor(0,0);
tft.fillScreen(myColors[11]);
len = strlen(title);
tft.setTextColor(myColors[6],myColors[11]);
tft.setCursor((tft.width()/2) - (len/2)*tft.getFontWidth(),0);
tft.println(title);
tft.setTextColor(myColors[1],myColors[11]);
tft.setFontSize(1,true);
tft.setTMargins(10, 2, 10, 2); //Setup a text window
// Setup PIP window #1 on screen page #4
tft.setTextColor(myColors[1],myColors[11]);
tft.selectScreen(SCREEN_4); // Select screen page 4
tft.fillScreen(myColors[13]);
tft.setFontSize(1,true); // Set 12x24 font size
tft.setCursor(0,0);
tft.setTextColor(myColors[0],myColors[13]);
tft.println(pip1);
tft.fillCircle(xw / 2, yh / 2, 100, myColors[2]);
// Setup PIP window #2 on screen page #5
tft.setTextColor(myColors[1],myColors[11]);
tft.selectScreen(SCREEN_5); // Select screen page 5
tft.fillScreen(myColors[6]);
tft.setFontSize(2,true); // Set 16x32 font size
tft.setCursor(0,0);
tft.setTextColor(myColors[0],myColors[6]);
tft.println(pip2);
tft.fillRect(xw - 300, yh - 200 , 100, 100, myColors[15]);
// Set screen page #1 as the active screen page
tft.selectScreen(SCREEN_1); // Select home page
}
void loop() {
char STR1[256];
uint32_t start = millis();
uint32_t finished = 0;
onOff = 1; // Enable PIP's
pipNo = 1; // Select and enable PIP #1
tft.PIP(onOff,pipNo,SCREEN_4,xp,yp,tft.width(),xd,yd,xw,yh);
pipNo = 2; //Select and enable PIP #2
tft.PIP(onOff,pipNo,SCREEN_5,xp,yp,tft.width(),xd+700,yd+215,xw,yh);
pipNo = 1; // Select and move PIP #1
drawBorder();
for(int i=0; i <= 700; i++) {
tft.PIP(onOff,pipNo,SCREEN_4,xp,yp,tft.width(),xd+i,yd,xw,yh);
delayMicroseconds(pipDelay);
tft.setTextColor(myColors[i % 22],myColors[11]);
tft.write(c); // Print character set in text window
c++;
if(c == 255)
c = 32;
}
drawBorder();
pipNo = 2; // Select and move PIP #2
for(int i=700; i >= 0; i--) {
tft.PIP(onOff,pipNo,SCREEN_5,xp,yp,tft.width(),xd+i,yd+215,xw,yh);
delayMicroseconds(pipDelay);
tft.setTextColor(myColors[i % 22],myColors[11]);
tft.print(c); // Print character set in text window
c++;
if(c == 255)
c = 32;
}
finished = millis()-start;
// Print some stats to the status line
sprintf(STR1,"pipDelay: %lu uS, Loop Cycle Time: %lu ms, Use pipDelay=0 for fastest Loop time.",(unsigned long)pipDelay, (unsigned long)finished);
tft.printStatusLine(0,myColors[13],myColors[11],STR1);
}
